Handset Configuration
2. In the Headset type drop-down list, select the corresponding headset type to be used.
If User headset profile is selected, see
User headset profile
If the preconfigured headset profiles does not match the headset or the audio performance is unsatisfactory,
a headset profile can be configured in the following way:
1. Select Connections → Headset → User headset profile.
2. In the Name of user headset profile field, enter an appropriate name. The name is visible and
selectable in the handset menu.
3. In the Headset mic adjustment drop-down list, select the microphone gain to be used.
4. In the Headset speaker adjustment drop-down list, select the speaker gain to be used.
Changing these parameters may result in a very high sound level which can cause hearing
damage. In addition, these parameters may result in lower sound quality such as noise and echo. If
the audio problems occur, it is noticable for the person listening on the conversation. Evaluate
carefully before applying.

5.40.2 Configuration of Headset Button

The headset answer button can be configured with a predefined function.
Configure a corded headset button
1. Select Connections → Headset.
2. In Headset type drop-down list, select the headset to be used.
3. In the Call with headset button drop-down list, select one of the following:
− Not activated - a call can only be answered or ended.
− Last called number - the last called number is dialled.
− Predefined number - a predefined number is called (if selected, continue with step 4) .
− Hook off - activates the post-dial function, that is, a dial tone is heard and the user can enter the
number to be called.
4. If required, enter the number to be dialled when the headset button is pressed in the Predefined
number field.
Configure a Bluetooth headset button
Refer to the user manual for the Bluetooth headset for more information about how to connect it
and use its answer button.
1. Select Connections → Bluetooth headset.
2. In the Call with headset button drop-down list, select one of the following:
− Not activated - a call can only be answered or ended.
− Last called number - the last called number is dialled.
− Predefined number - a predefined number is called (if selected, continue with step 3).
− Hook off - activates the post-dial function, that is, a dial tone is heard and the user can enter the
number to be called.
3. If needed, in Predefined number field, enter the number to be dialled when headset button is pressed.
54
User headset profile, page
CONFIGURATION MANUAL
Ascom d83 DECT Handset
54.
TD 93426EN / 28 January 2022 / Ver. C
