Handset Configuration
Figure 11. Messages Displayed in Chronological Order Regardless of Priority
New messages
Prio 1
13:59
Prio 1
13:59
DEF
ABC
GHI MNO
JKL
PQRS WXYZ
TUV
In Figure 11. Messages Displayed in Chronological Order Regardless of Priority, page
priority 1 is received at 13:59. Another message with priority 2 is received at 14:02 and is displayed. The
message with priority 1 is put in the message queue. The user needs to close the current message with
priority 2 to show the message with priority 1 in the queue. When closing the message with priority 2 it is
indicated as a read message in the Inbox.
5.33.3

Broadcast and Multicast Messaging

This feature is supported by the handset, but no parameter settings are required.

5.34 Message Templates

Handsets can be configured with predefined messages using the message template function. Provided that
both parties are connected via an IP-DECT system, a predefined message can be used in the following
ways:
• The user can decline the call but still acknowledge the receipt of the call by selecting a predefined
message and sending it to the caller.
• The user replies to an incoming text message by selecting a predefined message and sending it to the
message sender.
• The user can construct a text message from a predefined message.
5.34.1

Configure the Handset for Message Templates

To activate the message template function in the handset so that a user can decline a call with a predefined
message, perform the following steps using the WinPDM/Device Manager:
1. Open the Edit parameters dialog
2. Select Settings → Answering.
3. Locate the parameter Can reply with a message template when rejecting a call and set the value to
On.

5.34.2 Create Message Template Texts

A handset can be configured with up to five predefined messages. A message cannot exceed 50
characters. To create a message, performing the following steps in the WinPDM/Device Manager:
1. Open the Edit parameters dialog.
2. Select Settings → Messaging → Templates → Template <n> where n refers to the five message
templates numbered 1 to 5.
50
Prio 2
14:02
Prio 1
13:59
Prio 1
13:59
The user closes
the message
DEF
ABC
GHI MNO
JKL
PQRS WXYZ
TUV
Messaging Inbox
Prio 2
14:02
Prio 2
14:02
DEF
ABC
GHI MNO
JKL
PQRS WXYZ
TUV
TD 93426EN / 28 January 2022 / Ver. C
CONFIGURATION MANUAL
Ascom d83 DECT Handset
50, a message with
