CONFIGURATION MANUAL
Ascom d83 DECT Handset
2. In the Call behaviour drop-down list, select one of the following:
− No action - no action is performed when handset is placed in charger.
− End - the handset disconnects calls when placed in charger.
Some systems/PBXs require that the handset sends a DTMF tone to end a call, See
Send DTMF Tone when Pressing On-Hook key, page 22
− Put on Loudspeaker - the handset activates the loudspeaker mode when placed in charger.
5.16.3

Clear Lists when Inserted in Charger

The handset can be configured to clear lists when placed in a charger. The following message and call lists
are then cleared:
• Inbox
• Unsent
• Sent
• Call list
• Missed calls
To configure automatic clearing of lists when placed in a charger:
1. Select Connections → In charger.
2. In the Clear lists in charger drop-down list, select On.
5.17

Disable Homebase GAP Registration

When the feature is enabled, it is not possible to register to a home base. To disable homebase GAP
registration:
1. Select Systems.
2. In the Can the handset subscribe to a home base drop-down list, select No.

5.18 Early Encryption

Early encryption is used when DECT security is activated in the base station. This means that the radio link
is encrypted early before data is transmitted.
To enable early encryption in the handset, the Use Early Encryption parameter is set via the WinPDM/
Device Manager in the following way:
1. From the WinPDM/Device Manager, select Systems → System x.
2. Select Yes from the Use Early Encryption drop-down list.
If users experience connection problems when early encryption is turned on, the function may be turned off
in the handset by reconfiguring the handset through the WinPDM/Device Manager and setting the value of
the parameter to No. This can occur, for example, when the handset is being used in an environment where
highly reflected metallic surfaces are used in the construction of the locale.

5.19 Base Station Positioning

The approximate location of a handset can be sent with an alarm. The handset evaluates the field strength
ratio of the individual radio Base Stations and sends the best-rated Base Station ID to indicate the
approximate location of the handset.
TD 93426EN / 28 January 2022 / Ver. C
Handset Configuration
for configuration.
5.11.1
27
