CONFIGURATION MANUAL
Ascom d83 DECT Handset
1. Select Settings → Custom Sounds → Custom Sound X (where X represent 1 - 10).
2. Set the following parameters:
− Label - The name of the custom sound (required). The name is visible when mapping the custom
sound to a beep code later on.
− Melody - The text string represents a non-polyphonic sound. By default, example of melodies are
set for Custom Sound 1 - 7. See also
− Beat - The tempo in beats per minute to be used when playing the sound.
− Style - The ratio of note to rest period to be used when playing the sound.
− Instrument - The instrument to be used when playing the sound.
Map Beep Codes to Customized Sounds
1. Select Sound and Alerts → Custom Message Alert.
2. In the Beep code drop-down lists, select the customized sounds to be used for respectively beep
codes.
Enable Customized Sound.
1. Select Settings → Sound and Alert.
2. In the Message alert drop-down list, select Custom sounds according to beep code.

5.33.2 Examples of TTR and TTP Settings

Example 1
This example describes the message handling with the following message settings:
• TTP – Prioritize forever
• TTR – Close manually
It is recommended to use these settings if messages with the highest priority are always displayed
until the user closes the current message.
Figure 8. Queuing and Prioritizing for Messages with Equal Priorities
New messages
Prio 7
14:04
Prio 4
14:03
Prio 2
14:02
Prio 2
13:59
Prio 7
14:04
Prio 4
14:03
Prio 4
Prio 1
13:58
13:59
Prio 2
14:02
DEF
ABC
GHI MNO
JKL
PQRS WXYZ
TUV
In Figure 8. Queuing and Prioritizing for Messages with Equal Priorities, page
is received at 13:59 and is displayed in the handset. Another message with equal priority is received at
14:02 and is placed in the queue. If no messages with higher priority are received, the user needs to close
the currently displayed message to show the next message in the queue, in this case, the message
received at 14:02. The closed message is indicated as a read message in the Inbox.
TD 93426EN / 28 January 2022 / Ver. C
Appendix A Configure Custom Sounds, page
Prio 7
14:04
Prio 4
14:03
Prio 4
13:58
The user closes
the message
Prio 2
14:02
DEF
ABC
GHI MNO
JKL
PQRS WXYZ
TUV
Handset Configuration
70.
47, a message with priority 2
