CONFIGURATION MANUAL
Ascom d83 DECT Handset
• IR location indications
IR Location Data
To configure the handset to provide IR location data, perform the following procedure:
1. Press the Menu soft key.
2. Select Calls.
3. Select Admin menu.
The Admin menu is only visible if the Admin menu is activated. To activate the Admin menu,
see 6.1.1 Activating the Admin Menu, page
4. From the Admin menu, select Location info.
5. Select IR Location info. IR location information is displayed in the handset display as shown in
IR Location Information, page
Figure 6. IR Location Information
IR Location Indications
When the IR Location info screen is opened, the handset can be configured to provide additional indications
to the support engineer as the handset is carried into a valid location. A beep /LED indication can be
activated to indicate when valid locations are received. The activation parameters that can be configured
via the WinPDM/Device Manager are as follows:
Location → Common → Indicate location with beep.
• Off - The beep indication is turned off.
• Beep on new - The handset beeps when it receives a new valid location. A location is considered as
"new" when the location ID is changed for the current location.
• Beep always - The handset beeps when it is receives a valid location.
Location → Common → Indicate location with LED.
• Off - The LED indication is turned off.
• Blink always - The LED blinks when the handset receives a valid location.
Location Information during Call
When the Admin menu is activated and DECT location is enabled, the DECT location information screen can
be accessed during a call by pressing the soft key More and select Location info.
TD 93426EN / 28 January 2022 / Ver. C
64.
33.
Handset Configuration
Figure 6.
33
