CONFIGURATION MANUAL
Ascom d83 DECT Handset
• Text indication for alarm on multiple press
• Define multiple press
• ALS
If the parameters "ALS" and "Silent alarm" are set, no ALS is triggered after an alarm has been
sent. The ALS is not activated if an automatic call is established after an alarm has been sent.
• Silent alarm
If enabled, the indication of an alarm has been sent and received is disabled.
If the parameters "ALS" and "Silent alarm" are set, no ALS is triggered after an alarm has been
sent.
• Mode for automatic call after alarm
Any ongoing call is disconnected if this option is enabled and an alarm is triggered.
The call can be established in the following modes:
− Normal: the call is established as an ordinary call.
− Loudspeaking: the loudspeaker on the backside of the handset is turned on.
− Monitoring: a one-way speech channel is established, that is, the called part can only listen to an
conversation.
See also
5.27 Common Alarm Settings, page 37
Information about the handset location can also be sent along with an alarm, see
Positioning, page
27,
5.20 BLE Location, page
and
5.23 LF Location, page
5.28.1
Call Predefined Number without Sending Alarm
The push-button can be configured to dial the automatic call after alarm number without sending an alarm.
The following example describes how to configure the push-button (alarm on long press). The
corresponding settings can also be configured for the push-button when it is pressed twice or more (alarm
on multiple press).
Example of configuration:
1.
Select Alarm → Common.
2.
In the Number for automatic call after alarm field, enter the number to be dialed.
3.
Select Alarm → Alarm on long press.
4.
In the Alarm type for long press drop-down list, select Not used.
5.
In the Mode for automatic call after alarm drop-down list, select one of the following:
− Normal: the call is established as an ordinary call.
− Loudspeaking: the loudspeaker on the backside of the handset is turned on.
− Monitoring: a one-way speech channel is established, that is, the called part can only listen to an
conversation.
This configuration lets the user long press the push-button to dial the number without sending an alarm.
However, the push-button can be configured to send an alarm by pressing it twice (see Alarm type for
multiple press in chapter
TD 93426EN / 28 January 2022 / Ver. C
28,
35.
5.27 Common Alarm Settings, page
for additional parameter settings.
5.21 DECT Location, page
37).
Handset Configuration
5.19 Base Station
30,
5.22 IR Location, page 32
39
