Handset Configuration
Figure 4. BLE Location Information
BLE Location info
RSSI: -47 MP: -20
1: 00000004*,00000s
2: 3C908002*,00004s
3: 00000004*,00004s
4: 3C908002*, 00014s
dc: 00000
lc: 00000
Back
The information on the screen is updated every second.
BLE Location Indications
When the BLE Location info screen is opened, the handset can be configured to provide additional
indications to the support engineer as the handset is carried into a valid location. A beep/LED indication can
be activated to indicate when valid locations are received. The activation parameters that can be configured
via the WinPDM/Device Manager are as follows:
Location → Common → Indicate location with beep.
• Off - The beep indication is turned off.
• Beep on new - The handset beeps when it receives a new valid location. A location is considered as
"new" when the location ID is changed for the current location.
• Beep always - The handset beeps when it is receives a valid location.
Location → Common → Indicate location with LED.
• Off - The LED indication is turned off.
• Blink always - The LED blinks when the handset receives a valid location.
Location Information during Call
When the Admin menu is activated and BLE location is enabled, the BLE location information screen can be
accessed during a call by pressing the soft key More and select Location info.

5.21 DECT Location

The DECT location feature is used to keep track and report the location of DECT handsets. It is implemented
through DECT location devices, which transmit location information continuously. The location information
consists of a location ID and a Received Signal Strength Indication (RSSI) threshold value. Location
information is stored by handsets when the handset RSSI is stronger than the location device RSSI
threshold. The handset stores the four last received location IDs and the time that has elapsed since the
location IDs were received.
30
CONFIGURATION MANUAL
Ascom d83 DECT Handset
TD 93426EN / 28 January 2022 / Ver. C
