Function Display - Icom IP110H Operating Manual

1
BEFORE USING

Function display

Signal strength
• Displays the signal strength in 1 to 3 levels�
• " " blinks when you are out of a service area�
• " " is displayed if your transceiver is not
registered, or not connected to the Controller�
Area Call function* (p� 3-5)
Displayed when the Area Call function is ON�
Recording function* (p� 3-15)
• " " is displayed when the Recording function
is ON�
• " " blinks when there is new recorded data�
• " " blinks while recording audio�
Key Lock function (p� 1-6)
Displayed when the Key Lock function is ON�
Pocket Beep function* (p� 3-10)
• Displayed when the Pocket Beep function is ON�
• Blinks when a call is received� This icon blinks
until the transceiver returns to the Standby mode
after a received signal disappears�
P-Bell function* (p� 3-10)
Displayed when the P-Bell function is ON�
Bluetooth function (p� 5-5)
• " " is displayed when the Bluetooth function is
ON�
• " " is displayed when a Bluetooth device is
connected to the transceiver�
VOX function* (p� 3-10)
Displayed when the VOX function is ON�
Receive-only*
Displayed when transmission is inhibited�
* May be usable, depending on the Controller setting�
An "F" blinks while updating the firmware:
• You cannot turn OFF the transceiver until the firmware download and update are finished� Place the transceiver in a good
signal level area�
• The transceiver will automatically restart when the update is finished�
• If the "F" does not blink, restart the transceiver�
• If the battery status indication is "
the battery, restart the transceiver, and then update the firmware�
" (nearing exhaustion) or "
1-5
Vibration function*
Displayed when the Vibration function is ON�
Mute function* (p� 3-9)
Displayed when the audio is muted�
USB connection
Displayed when a USB device is connected
through a USB cable�
Remaining battery capacity
• Displays the remaining capacity in 4 steps�
: The battery has sufficient capacity.
: The battery is a little exhausted.
: The battery is nearing exhaustion.
(Charging is necessary�)
: The battery is almost fully exhausted.
(Charging is required�)
• " " is displayed while charging�
About the Call types
All/Group Call
Talkgroup Call* (pp� 3-6 ~ 3-8)
Individual Call
Phone Call
" (exhausted), the firmware update will not start� Charge
