INSTRUCTION MANUAL
HYBRID IP TRANSCEIVER
IP730D
IP740D
INTRODUCTION
1
ACCESSORIES
2
BEFORE USING
3
USING THE CELLULAR MODE
4
USING THE IDAS MODE
5
OTHER FUNCTIONS
6
SET MODE
7
FOR YOUR REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP730D and is the answer not in the manual?

Questions and answers

Summary of Contents for Icom IP730D

  • Page 1 INSTRUCTION MANUAL INTRODUCTION ACCESSORIES HYBRID IP TRANSCEIVER BEFORE USING IP730D USING THE CELLULAR MODE IP740D USING THE IDAS MODE OTHER FUNCTIONS SET MODE FOR YOUR REFERENCE...
  • Page 2 Icom Inc. is under license. contamination. AquaQuake is a trademark of Icom Incorporated. • The use of Icom transceivers with any equipment that is All other products or brands are registered trademarks or not manufactured or approved by Icom. trademarks of their respective holders.
  • Page 3 Section ACCESSORIES Supplied accessories1-2 Attachable accessories1-2 D Antenna 1-2 D Battery pack/Battery case 1-3 D Belt clip 1-3...
  • Page 4 ACCESSORIES Supplied accessories Battery pack Belt clip Connector cover and screw NOTE: Some accessories are not supplied, or the shape is different, depending on the transceiver version. Attachable accessories D Antenna Connect an optional antenna to the antenna connector CAUTION: •...
  • Page 5 ACCESSORIES Attachable accessories (Continued) D Battery pack/Battery case CAUTION: • DO NOT attach or detach the battery pack or the battery case when the transceiver is wet or soiled This may result in water or dust getting into the transceiver, battery pack, or battery case and may damage them CAUTION: Keep the battery pack terminals clean It’s a good idea to occasionally clean them...
  • Page 6: Table Of Contents

    Section BEFORE USING Panel description ������������������������������������������������������������������������������������2-2 D Front, top and side panels ��������������������������������������������������������������2-2 D Status indicator �������������������������������������������������������������������������������2-2 D Multi-connector �������������������������������������������������������������������������������2-2 D About the assignable key functions ������������������������������������������������2-2 Function display��������������������������������������������������������������������������������������2-3 D Cellular mode ����������������������������������������������������������������������������������2-3 D IDAS mode �������������������������������������������������������������������������������������2-3 D Cellular/IDAS mode ������������������������������������������������������������������������2-3 Basic operation ���������������������������������������������������������������������������������������2-4 D Turning ON the transceiver �������������������������������������������������������������2-4 D Adjusting the volume level ��������������������������������������������������������������2-4...
  • Page 7: Section 2 Before Using

    BEFORE USING Panel description D Front, top and side panels D Multi-connector Connects to an optional speaker microphone or headset� Rotary Selector L Turn OFF the transceiver before attaching or detaching the microphone� Antenna [VOL] Connector CAUTION: DO NOT use the transceiver without the Status connector cover or optional equipment attached�...
  • Page 8: Function Display

    BEFORE USING Function display IDAS mode Cellular mode D Cellular mode D Cellular/IDAS mode Displays the signal strength level by 3 bars� • Displayed when the Record function is L The connected network type (4G or 3G) is ON� (p� 5-9) displayed on the left top�...
  • Page 9: Basic Operation

    BEFORE USING Basic operation D Turning ON the transceiver NOTE: Before using the transceiver for the first time, the battery pack must be fully charged for optimum life and operation� See the BATTERY CHARGING section on the boxed INSTRUCTIONS� z Rotate [VOL] clockwise to the 12 o’clock position to turn ON the transceiver� L The dial is made tight for dust and water resistance�...
  • Page 10 Section USING THE CELLULAR MODE Basic operation ��������������������������������������������������������������������������������������3-2 D Operating keys ��������������������������������������������������������������������������������3-2 D Receiving and Transmitting ������������������������������������������������������������3-3 Advanced operation��������������������������������������������������������������������������������3-4 D About the Talkgroup Call �����������������������������������������������������������������3-4 D Selecting a Talkgroup number ��������������������������������������������������������3-5 D Sending a message (Message Call) �����������������������������������������������3-6 D Browsing received messages ���������������������������������������������������������3-7 D Status Call ��������������������������������������������������������������������������������������3-7 D Toggling the SIM card ���������������������������������������������������������������������3-8 D Pocket Beep function ����������������������������������������������������������������������3-8...
  • Page 11: Section 3 Using The Cellular Mode

    USING THE CELLULAR MODE Basic operation D Operating keys Rotary Selector Rotary Rotate to select a channel, scroll the Selector screen, or move the cursor� [Emer] Hold down until “Emergency” is [VOL] displayed to send an Emergency call� (p� 5-5) [Emer] [PTT] Hold down to transmit, release to...
  • Page 12: D Receiving And Transmitting

    USING THE CELLULAR MODE Basic operation (Continued) D Selecting a call-to party 1� Push [Address] to display the Address book� L The Address book is displayed� 2� Push [Address] several times to toggle the call type� L The selectable call type may differ, depending on a presetting. 3�...
  • Page 13: Advanced Operation

    The Talkgroup Call function enables the user to communicate with call-to parties in the same Talkgroup� For example, in the illustration below, when the IP730D “00105” in its normal group “10002” selects Talkgroup “20001,” it is excluded from group “10002,” and can communicate with only the transceivers “00004” and “00108”...
  • Page 14: D Selecting A Talkgroup Number

    USING THE CELLULAR MODE Advanced operation (Continued) D Selecting a Talkgroup number You can select a Talkgroup number if the Talkgroup Call function is assigned to the [FUNC] key� Ask your dealer for details� 1� Push [FUNC] to display the Function� •...
  • Page 15: D Sending A Message (Message Call)

    USING THE CELLULAR MODE Advanced operation (Continued) D Sending a message (Message Call) You can send a message, depending on a presetting� Ask your dealer for details� 1. Selecting a call-to party 1� Push [Address] to display the Address book� •...
  • Page 16: D Browsing Received Messages

    USING THE CELLULAR MODE Advanced operation (Continued) D Browsing received messages You can browse received messages, depending on a presetting� Ask your dealer for details� 1� Push [Call History] to display the Call history� • The Call history is displayed� 2�...
  • Page 17: D Toggling The Sim Card

    USING THE CELLULAR MODE Advanced operation (Continued) D Toggling the SIM card The transceiver has two SIM card slots, SIM 1 and SIM 2� You can toggle which SIM card to use in the Detailed Set mode� 1� Turn OFF the transceiver, if it is turned ON� 2�...
  • Page 18 Section USING THE IDAS MODE Basic operation ���������������������������������������������������������������������������������������4-2 D Operating keys ��������������������������������������������������������������������������������4-2 D Selecting a Zone �����������������������������������������������������������������������������4-3 D Selecting a channel ������������������������������������������������������������������������4-3 D Receiving and transmitting �������������������������������������������������������������4-3 D Transmitting Notes ��������������������������������������������������������������������������4-3 Other functions ���������������������������������������������������������������������������������������4-4 D Radio Access Number (RAN) ���������������������������������������������������������4-4 D Encryption function �������������������������������������������������������������������������4-4...
  • Page 19: Basic Operation

    USING THE IDAS MODE Basic operation D Operating keys Rotary Selector Rotary Rotate to select a channel, scroll the Selector screen, or move the cursor� [Emer] Hold down until “Emergency” is [VOL] displayed to send an Emergency call� (p� 5-5) [Emer] [PTT] Hold down to transmit, release to...
  • Page 20: D Selecting A Zone

    USING THE IDAS MODE Basic operation (Continued) D Selecting a Zone D Transmitting Notes Certain channels are grouped together and assigned Transmit inhibit function to a Zone according to their intended use� The transceiver has several inhibit functions which For example, Analog channels ‘Station 1’ and ‘Station restrict transmission under the following conditions: 2’...
  • Page 21: Other Functions

    USING THE IDAS MODE Other functions D Radio Access Number (RAN) D Encryption function Radio Access Number (RAN) is a signaling system The Encryption function enables voice scrambling, designed for digital radio communications� When a which provides private digital communication between channel is set up with a RAN, the squelch will open stations�...
  • Page 22 Section OTHER FUNCTIONS D About the VS-3 Bluetooth headset �������������������������������������������������5-2 D Pairing with a Bluetooth device �������������������������������������������������������5-3 D Settings for the Bluetooth function ��������������������������������������������������5-3 D Disconnecting a paired device ��������������������������������������������������������5-4 D Initializing the Pairing lists ���������������������������������������������������������������5-4 Using the Emergency call function ���������������������������������������������������������5-5 D The Man Down function ������������������������������������������������������������������5-6 D The Lone Worker function���������������������������������������������������������������5-7 D The Stationary Detection function ���������������������������������������������������5-8...
  • Page 23: Section 5 Other Functions

    [PTT] switch� Microphone • The [FWD], [RWD], and [PLAY] keys on the VS-3 are disabled while using the headset with the IP730D or IP740D� [PTT] • If the headset does not work correctly, even if the power is ON, push [VOL] (+) [RESET] with a pin to force power OFF�...
  • Page 24: D Pairing With A Bluetooth Device

    • The transceiver searches for a Bluetooth device� L Push [CLR/Lock] to cancel searching� Search BT Device • If found, the device’s name and BD address are displayed on the screen� ICOM BT-002 (Example: ICOM BT-002) Search BT Device 2� Push[▲]or[▼]toselecttheheadsettopairandconnect,andthenpush Connect [Call History]�...
  • Page 25: D Disconnecting A Paired Device

    1� In the standby screen, push [FUNC] several times to select “Pairing List�” 2� Push[▲]or[▼]toselectthedevicetodisconnect,andthenpush[CallHistory]. Pairing List • “Unconnected” is displayed if the headset or device is correctly disconnected� ICOM BT-002 L Do the same steps to reconnect to the Bluetooth device� Unconnected D Initializing the Pairing lists If you have problems with Bluetooth operation, initialize the pairing lists, as shown below�...
  • Page 26: Using The Emergency Call Function

    • Returns to the Standby screen when you release [PTT]� NOTE: The Emergency function may not properly work, depending on the surrounding environment such as obstructions, weather condition, and so on� Icom is not responsible for the destruction or damage caused by using the Emergency Call function�...
  • Page 27: D The Man Down Function

    NOTE: The Man down function may not properly work, depending on the surrounding environment such as obstructions, weather condition, and so on� Icom is not responsible for the destruction or damage caused by using the Man Down function�...
  • Page 28: D The Lone Worker Function

    NOTE: The Lone Worker function may not properly work, depending on the surrounding environment such as obstructions, weather condition, and so on� Icom is not responsible for the destruction or damage caused by using the Lone Worker function�...
  • Page 29: D The Stationary Detection Function

    Icom is not responsible for the destruction or damage Icom is not responsible for the destruction or damage caused by using the Stationary Detection function� caused by using the Motion Detection function�...
  • Page 30: Using The Voice Recorder Function

    OTHER FUNCTIONS Using the Voice Recorder function The transceiver can record and playback up to 10 of the latest incoming calls, depending on a presetting� L Records up to 4 minutes per call� If a call is longer than 4 minutes, the older will be automatically deleted�...
  • Page 31: Using Assignable Keys

    OTHER FUNCTIONS Using assignable keys Functions shown below may be assigned to the [Sub PTT], [Side 1], and [Side 2] keys, depending on a presetting� Hold down or push these keys to use assigned functions� You can also assign these functions in the Detailed Set mode (p�...
  • Page 32: Using The Dual Mode

    OTHER FUNCTIONS Using the Dual mode You can use the Cellular mode and IDAS mode at the same time� D Main mode and Sub mode When the Dual mode is selected, the Main mode and Sub mode are displayed as shown to the right� Main mode Sub mode Switching the operating mode:...
  • Page 33 Section SET MODE Using the Set mode ��������������������������������������������������������������������������������6-2 D Basic Set mode �������������������������������������������������������������������������������6-2 D Detailed Set mode ��������������������������������������������������������������������������6-2 D Using the Set mode ������������������������������������������������������������������������6-2 Set mode items���������������������������������������������������������������������������������������6-3 D Common �����������������������������������������������������������������������������������������6-3 D Cellular ��������������������������������������������������������������������������������������������6-7 D IDAS �����������������������������������������������������������������������������������������������6-9...
  • Page 34: Section 6 Set Mode

    SET MODE Using the Set mode You can use the Set mode to set infrequently changed values or function settings� The transceiver has 2 types of Set modes, as shown below� L You cannot transmit or receive while the transceiver is in the Set mode� D Basic Set mode 1�...
  • Page 35: Set Mode Items

    SET MODE Set mode items The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Common Item Description Option/range Default LOG CLEAR...
  • Page 36 SET MODE Set mode items (Continued) The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Common Item Description Option/range Default...
  • Page 37 SET MODE Set mode items (Continued) The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Common Item Description Option/range Default...
  • Page 38 SET MODE Set mode items (Continued) The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Common Item Description Option/range Default...
  • Page 39: D Cellular

    SET MODE Set mode items (Continued) The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Cellular Item Description Option/range Default...
  • Page 40 SET MODE Set mode items (Continued) The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Cellular Item Description Option/range Default...
  • Page 41: D Idas

    SET MODE Set mode items (Continued) The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D IDAS Item Description Option/range Default...
  • Page 42 Section FOR YOUR REFERENCE Specifications ����������������������������������������������������������������������������������������7-2 D General �������������������������������������������������������������������������������������������7-2 D 4G (LTE)/3G (W-CDMA) ����������������������������������������������������������������7-2 D IDAS �����������������������������������������������������������������������������������������������7-2 D Transmitter ��������������������������������������������������������������������������������������7-2 D Receiver ������������������������������������������������������������������������������������������7-3 Options ��������������������������������������������������������������������������������������������������7-4 D Battery pack/Battery case ���������������������������������������������������������������7-4 D Chargers �����������������������������������������������������������������������������������������7-4 D Antennas �����������������������������������������������������������������������������������������7-4 D Others ���������������������������������������������������������������������������������������������7-4 D Using the BC-227 DESKTOP CHARGER ��������������������������������������7-5 D Using the BC-226 DESKTOP CHARGER ��������������������������������������7-6 D Using the BP-305 battery case ������������������������������������������������������7-7 D Using the LC-195 leather case ������������������������������������������������������7-8...
  • Page 43: D General

    0�25 W • Receiver sensitivity (QPSK): –95 dBm maximum, –102 dBm typical D IDAS • Frequency range: IP730D 136 MHz ~ 174 MHz IP740D 350 MHz ~ 470 MHz, 400 MHz ~ 520 MHz • Number of conventional channels: 128 ch / 8 Zone •...
  • Page 44: D Transmitter

    70 dB minimum� 90 dB typical EUR/AUS version 0�25 uW (Less than 1GHz), 1�0 uW (More than 1GHz) • Adjacent channel power: IP730D 60 dB minimum 70 dB typical IP740D 60 dB minimum 64 dB typical • FSK Error: 5 % maximum, 1 % typical •...
  • Page 45: Options

    FOR YOUR REFERENCE Options D Battery pack/Battery case • FA-SC01U/FA-SC02U/FA-SC03U/FA-SC25U/ FA-SC57U/FA-SC72U/ • BP-302/BP-303 BATTERY PACK UHF ANTENNAS Battery Voltage Capacity Approximate FA-SC01U 350–400 MHz pack battery life* FA-SC02U 330–380 MHz BP-302 7�2 V 1950 mAh (Minimum) 15 hours FA-SC03U 380–430 MHz FA-SC25U 400–430 MHz 2010 mAh (Typical) FA-SC57U 430–470 MHz...
  • Page 46: D Using The Bc-227 Desktop Charger

    FOR YOUR REFERENCE Options (Continued) D Using the BC-227 DESKTOP CHARGER Turn OFF Charging time: approximately 4�4 hours for the BP-303� CAUTION: Before using the charger, read the Battery pack ‛Battery caution’ and ‛Charging caution’ on the INSTRUCTIONS that boxed with the transceiver� Status indicator Light color Status...
  • Page 47: D Using The Bc-226 Desktop Charger

    FOR YOUR REFERENCE Options (Continued) D Using the BC-226 DESKTOP CHARGER Charging time: approximately 4�2 hours for the BP-303� Battery pack Turn OFF CAUTION: Before using the charger, read the ‛Battery caution’ and ‛Charging caution’ on the INSTRUCTIONS that boxed with the transceiver� Status indicator Light color Status...
  • Page 48: D Using The Bp-305 Battery Case

    FOR YOUR REFERENCE Options (Continued) D Using the BP-305 battery case Install 5 × AA (LR6) size alkaline batteries, as shown below� 4� Insert the battery holder to the battery case until 1� Open the battery case� the tab makes a ‘click’ sound� 2�...
  • Page 49: D Using The Lc-195 Leather Case

    FOR YOUR REFERENCE Options (Continued) D Using the LC-195 leather case The LC-195 is a leather case that is usable when the battery pack is attached� Adjust the fixing position with the hook-and-loop fasteners� Attach an optional MB-57L shoulder strap if necessary Hook-and-loop fastener Adjust here You can charge even when the leather case is attached, as shown below�...
  • Page 50: Troubleshooting

    FOR YOUR REFERENCE Troubleshooting The following conditions are not due to a malfunction� Check before sending a request for repair� No power comes ON. • Loose connection of the battery pack� - Clean the battery pack terminals� • The battery is exhausted� - Charge the battery pack�...
  • Page 51 FOR YOUR REFERENCE Troubleshooting (Continued) The charging indicator blinks orange, or alternately blinks orange and green • The battery pack is not properly inserted� - Properly insert the battery pack� (p� 7-5) • Charging the battery pack outside of the chargeable temperature range� - Charge the battery pack in the chargeable temperature range (0˚C to 60˚C (32˚F to 140˚F))�...
  • Page 52 A7605-3EX 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan © 2020 Icom Inc. Aug. 2020...
