Cafection Encore GROUND Service & Installation Manual page 80

WALL
1
9 4 "
6
1
15 4 "
CHUTE
HOLE
Leveling glides (4X)
COUNTERTOP
3
8 "
1
7 4 "
"HOLE EDGES SHOULD BE SEALED WITH SILICONE OR AN APPROPRIATE
SEALANT FOR PROTECTION AGAINST WATER DAMAGE"
Annex 4
1
2 2 "
Minimal
clearance
7
14 8 "
1
4 4 "
7
4 8 "
COUNTERTOP
WALL
