Outlet Valves - Cafection Encore GROUND Service & Installation Manual

8.3

Outlet Valves

Inspection: quarterly
Preventive maintenance: every 10,000 cycles
To avoid any issue related to mineral deposits, Cafection recommends rebuilding all three (3) outlet
valves at the same time using the valve repair kits (PETAN45, one kit needed for each valve).
Valve Leakage
Identify the leaking valve, change it or rebuild it.
If the leak originates from under the body of the valve or from the tank exit, try changing the conical
mounting seal in the first instance.
If the coffee valve is not watertight, water will accumulate in the brew chamber.
If it drips all night, the first coffee of the morning will be lukewarm.
The leakage may also cause the brew chamber to flood.
WARNING! Water is VERY HOT!
Removing and Installing the Valves
If a water filtration system is installed on the brewer, it is recommended to inspect it
on a monthly basis.
Double valve
68
SERVICE & INSTALLATION MANUAL for Cafection's Encore Ground
1. Turn off the machine and remove the back panel.
2. Unplug the tank lid's connectors (fig. 1.1) and the valves
(fig. 1.2).
3. Completely drain water from the tank (see section 9.1).
4. Remove the tubes.
5. Unscrew the guard to be able to remove the tank.
6. Tilt the tank forward to have access to the valves.
7. Remove the valves. Replace or rebuild them.
8. Reinstall by repeating the steps in reverse order.
Single valve
Fig. 1.2
Valves
www.cafection.com
Tank guard
Conical
mounting seals
Valves
ENCORE GROUND Rev. 1 2021-10
800-561-6162
Connectors
Fig. 1.1
Tank lid
