SERVICE & INSTALLATION MANUAL for Cafection's Encore Ground
www.cafection.com
3.7
Hot Water Tank
Make sure the equipment is unplugged when servicing.
Access the hot water tank by removing the back panel.
See images below for tank lid details.
See section 8.4 for preventive maintenance.
Heater safety switch
Left Side View
Heating element
connector
Heater safety
switch
ENCORE GROUND Rev. 1 2021-10
800-561-6162
Heating element wire
Water tank
Water level switch (float)
Right Side View
Water level switch
(float)
Water temperature probe
15
