4.11
Chute Kit Installation (Optional)
1. Open the brewer's door and remove the front pannel.
2. Insert the chute base inside the chute hole of the cabinet.
3. Insert the waste chute into the chute base.
4. Install the front panel by aligning its metal bracket with the metal bracket fixed on the brew
See Annex 4 for the chute base hole positioning diagram.
26
SERVICE & INSTALLATION MANUAL for Cafection's Encore Ground
group assembly.
www.cafection.com
800-561-6162
Front panel
Waste chute
Chute base
ENCORE GROUND Rev. 1 2021-10
