Main Board (Pcb) Description - Cafection Encore GROUND Service & Installation Manual

3.6.1
Interactive Switches and Buttons
1. SW1 Setup Button (White)
2. SW2 Service Button (Black)
14
SERVICE & INSTALLATION MANUAL for Cafection's Encore Ground

Main Board (PCB) Description

This button gives access to the
parameters of the machine and
products through Service mode
(see section 6.2 for details).
There are two functions for this
button:
-In Selection mode, pressing this
button will enter the touch screen
calibration utility.
-In Service mode, pressing this
button will display the Factory reset
pop-up menu. This menu allows the
user to reset several settings back
to factory: configuration, passwords
and drink settings.
www.cafection.com
LEDs light up to indicate
the following statuses:
DS1 Power 5 V OK
DS15 Low water level
DS13 Brew group out of park position
DS14 Filter paper roll detected
DS18 Water detected in the overflow tray
DS20 Power 3.3V OK
DS30 Computer COM indicator
LEDs light up to indicate
the following parts are in use:
24 V DC Outputs:
DS2 Ingredients motor (coffee # 1)
DS3 Ingredients motor (coffee # 2)
DS4 Ingredients motor (soluble # 1)
DS5 Ingredients motor (soluble # 2)
DS6 Hot water valve (coffee)
DS7 Hot water valve (soluble)
DS8 Hot water dispensing valve
DS21 Soluble whipper motor
DS23 Auxiliary
DS25 Fan
120 V AC Outputs:
DS9 Brew group motor
DS10 Water inlet valve
DS11 N/A
DS12 N/A
ENCORE GROUND Rev. 1 2021-10
800-561-6162
