INITIAL SETUP

Before the installation of the brewer on location, it is strongly suggested to unpack, inspect and bench test
the machine before it leaves the warehouse.
4.1

On-Site Installation Requirements

4.1.1

Operating Environment

Equipment is for indoor use only.
4.1.2

Power Supply

Make sure each unit has its own electrical circuit and is located within 6 feet of the
dedicated electrical outlet.
Use only a polarized grounded receptacle.
Domestic 120 V AC / 60 Hz - 15 A circuit.
4.1.3

Water Supply

Use a plastic 1/4" or 3/8" (outside diameter) dedicated line branched off a larger line. An
easily accessible shut off valve up stream of the unit is highly recommended for ease of
installation.
Cold tap water pressure should be at least 20 psi and no more than 80 psi.
4.1.4

Tools Required

- #2 Phillips screwdriver
- Regular medium pliers
- Adjustable wrench
- Level indicator
Other tools may be required depending on the type of water supply tubing and
location.
4.1.5

Clearance

Height
Width
Depth
Back
Clearance
See Annex 4 for waste chute positioning.
See Annex 5 for a diagram illustrating required clearance.
ENCORE GROUND Rev. 1 2021-10
800-561-6162
Unit Clearances Allowance for
32 1/8" 48 1/8"
11 1/2" 23 1/2"
24 1/2" 33"
2 1/2"
6"
Removing top lid.
Accessing lock (left side) and opening door (right side).
Opening door (front) and back clearance.
Clearance for water hookup, hoses and adequate air
circulation.
Needed only if a filtration system is installed behind
the machine.
