SET COMMUNICATION:

This section define the fundamental communication parameters of two buses, NMEA2000 and CANopen.
By Pressing the "Set Communication" button from the main window for SW67461 (Fig. 2) the window
"Set Communication" appears (Fig. 3).
The means of the fields for "NMEA 2000" are:
In the field "Baudrate" the data rate of CANopen is defined;
If the field "Enable Peer to
NMEA2000 messages received.
In the field "ID Device" the NMEA2000 ID for the converter is defined.
The means of the fields for "CANopen" are:
In the field "ID Device" the CANopen ID for the converter is defined;
In the field "Baudrate" the data rate of the CANopen is defined;
If the field "Set Operational State at
defined. I.e. if it is checked the board starts in Operational State, else it starts in Pre-
Operational;
If the field "Network Start at
defined. I.e. if it is checked the board sends a command to set the Operational State of all the
devices present in the network. In the field
command for the CANopen is defined;
If the field "Enable SDO
"TimeOut SDO (1/10ms)" the timeout for the SDO requests is defined;
If the field "Enable NodeGuarding" is checked, the NodeGuarding function is enabled. It is
possible to send the NodeGuarding information on NMEA2000 checking the option
State on NMEA2000
field;
ADFweb.com Srl – IT31010 – Mareno – Treviso
Peer" is checked, the gateway will mask the Source Address of the
Start-up" is checked, the state of the CANopen is
Start-up" is checked, the state of the CANopen network is
"Delay (s)" the delay before sending the network
Client" is checked, the SDO Client function is enabled. In the field
Network" with the defined delay in
User Manual NMEA2000 / CANopen
Document code: MN67461_ENG
"Send Nodes
"Send Frames every (ms)"
INFO: www.adfweb.com
Revision 1.000 Page 17 of 36
Page 17 of 36
Figure 3: "Set Communication" window
