ADF Web HD674-A002 User Manual

Modbus tcp slave / modbus master - converter

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Industrial Electronic Devices

User Manual

Revision 1.000

English

Modbus TCP Slave / Modbus Master –

Converter

(Order Code: HD674-A002)

For Website information:

www.adfweb.com?Product=HD674-A002

For Price information:

www.adfweb.com?Price=HD674-A002

Benefits and Main Features:

Very easy to configure

Wide supply input range

Electrical isolation

Industrial temperature range:

-40°C / 105°C (-40°F / 221°F)

User Manual

ADFweb.com Srl – IT31010 – Mareno – Treviso

User Manual Modbus TCP Slave / Modbus Master - Converter

Document code: MN674-A002_ENG

For others Gateways / Bridges:

J1939 to Modbus

Need help?

Do you have a question about the HD674-A002 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD674-A002

Page 1 Revision 1.000 Page 1 of 28 Industrial Electronic Devices User Manual Revision 1.000 English Modbus TCP Slave / Modbus Master – Converter (Order Code: HD674-A002) For Website information: For others Gateways / Bridges: www.adfweb.com?Product=HD674-A002 J1939 to Modbus See also the following links: For Price information: www.adfweb.com?Product=HD67212...
Page 2: Table Of Contents
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 2 of 28 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated...
Page 3: Security Alert
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 3 of 28 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
Page 4: Examples Of Connection
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 4 of 28 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5: Connection Scheme
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 5 of 28 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD674-A002-E4x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6 User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 6 of 28 Industrial Electronic Devices Figure 1b: Connection scheme for HD674-A002-E7x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 7: Characteristics
CHARACTERISTICS: The “HD674-A002” series are rugged devices used to interface Modbus RTU Slave devices with Modbus TCP Master network. With its particular enclosure, equipped with four fixing lugs, makes available the mounting of the device in any plane surface (horizontal, vertical, oblique).
Page 8: Power Supply
POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax Vmin Vmax HD674-A002-Exx-xx Consumption at 24V DC: Device W/VA HD674-A002-Exx-xx Caution: Not reverse the polarity power HD674-A002-E4x-xx HD674-A002-E7x-xx Note: It is possible to use also negative tensions.
Page 9: Leds
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 9 of 28 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
Page 10: Rs485
Revision 1.000 Page 10 of 28 Industrial Electronic Devices RS485: The connection of the RS485 in the HD674-A002-E4x-xx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page.
Page 11: Ethernet
ETHERNET: The connection of Ethernet in the HD674-A002 device must be made with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable.
Page 12: Use Of Compositor Sw674-A002
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 12 of 28 Industrial Electronic Devices USE OF COMPOSITOR SW674-A002: To configure the Converter, use the available software that runs with Windows called SW674-A002. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 13: New Project / Open Project
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 13 of 28 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “...
Page 14: Software Options
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 14 of 28 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 15: Set Communication
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 15 of 28 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, Modbus TCP Slave and Modbus Master. By Pressing the “Set Communication”...
Page 16 User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 16 of 28 Industrial Electronic Devices If the field “No TCP frame on RTU Timeout” is checked, the Converter don’t sends back the reply on TCP (error response) if the Slave RTU interrogated has not replied.
Page 17: Operation Mode
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 17 of 28 Industrial Electronic Devices OPERATION MODE: OUTING A few characteristics of the Modbus RTU package have been modified in the standard of the Modbus TCP protocol. Two bytes of the final CRC were eliminated (no longer necessary for the information to reach its already corrected destination).
Page 18: Translate Table
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 18 of 28 Industrial Electronic Devices TRANSLATE TABLE Within the section “Translate Table” it is possible to define the variables that can be read or written by the TCP bus on the RTU bus when the device is in NAT mode.
Page 19: Enabled Functions
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 19 of 28 Industrial Electronic Devices ENABLED FUNCTIONS By pressing the “Enabled Functions” button from the main window for SW674-A002 (Fig. 2), the window “Enabled Functions” appears (Fig. 5).
Page 20: Update Via Udp
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 20 of 28 Industrial Electronic Devices UPDATE VIA UDP: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary.
Page 21 A002 device. Note: When you receive the device, for the first time, you also have to update the Firmware in the HD674-A002 device. Warning: If Fig. 7 appears when you try to do the Update try these points before seeking assistance: Try to repeat the operations for the updating;...
Page 22: Mechanical Dimensions
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 22 of 28 Industrial Electronic Devices MECHANICAL DIMENSIONS: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 23 User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 23 of 28 Industrial Electronic Devices Type A ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 24 User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 24 of 28 Industrial Electronic Devices Type B ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 25 User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 25 of 28 Industrial Electronic Devices Type C ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 26: Order Code
4: MiniFit 7: SuperSeal 1.5 Enclosure Type E: Metal enclosure Device Family HD674-A002 = Modbus TCP Slave / Modbus Master - Converter ACCESSORIES: Order Code: AC34011 Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V DC Order Code: AC34012 Rail DIN - Power Supply 220/240V AC 50/60Hz –...
Page 27: Disclaimer
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 27 of 28 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 28: Warranties And Technical Support
User Manual Modbus TCP Slave / Modbus Master - Converter Document code: MN674-A002_ENG Revision 1.000 Page 28 of 28 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
