UPDATE DEVICE USB:
By pressing the

"Update Device

necessary, using the USB port.
In order to load the parameters or update the firmware in the device, follow these
instructions:
Connect the USB cable from your PC to the Converter;
Turn ON the converter (it starts in Boot Mode);
Select the "COM port";
Select which operations you want to do.
Press the "Execute update
When all the operations are "OK", disconnect the USB cable.
ADFweb.com Srl – IT31010 – Mareno – Treviso
USB" button it is possible to load the created Configuration into the device, and also the Firmware if is
firmware" button to start the upload;
User Manual NMEA2000 / CANopen
Document code: MN67461_ENG Revision 1.000 Page 27 of 36
Page 27 of 36
Figure 12: "Update Device" windows
