J1939 / Modbus Slave – Converter

(Order Code: HD67432)

For Website information:

www.adfweb.com?Product=HD67432

For Price information:

www.adfweb.com?Price=HD67432

Benefits and Main Features:

Very easy to configure

Wide supply input range

Electrical isolation

Industrial temperature range:

-40°C / 105°C (-40°F / 221°F)

User Manual

ADFweb.com Srl – IT31010 – Mareno – Treviso

User Manual J1939 / Modbus Slave

Document code: MN67432_ENG

For other Gateways / Bridges:

CAN from/to Modbus

Need help?

Do you have a question about the HD67432 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD67432 Series

Page 1 User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 1 of 32 Industrial Electronic Devices User Manual Revision 1.100 English J1939 / Modbus Slave – Converter (Order Code: HD67432) For Website information: www.adfweb.com?Product=HD67432 For Price information: www.adfweb.com?Price=HD67432 Benefits and Main Features: For other Gateways / Bridges: Very easy to configure...
Page 2: Table Of Contents
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 2 of 32 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: Page INDEX Updated...
Page 3: Security Alert
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 3 of 32 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
Page 4: Example Of Connection
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 4 of 32 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5: Connection Scheme
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 5 of 32 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67432-E4x-xxx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6 User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 6 of 32 Industrial Electronic Devices Figure 1b: Connection scheme for HD67432-E7x-xxx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 7: Characteristics
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 7 of 32 Industrial Electronic Devices CHARACTERISTICS: The “HD67432” series are rugged devices used to interface J1939 devices with Modbus Master. With his particular enclosure, equipped with four fixing lugs, makes available the mounting of the device in any plane surface (horizontal, vertical, oblique).
Page 8: Power Supply
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 8 of 32 Industrial Electronic Devices POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax Vmin Vmax...
Page 9: Leds
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 9 of 32 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
Page 10: Rs485
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 10 of 32 Industrial Electronic Devices RS485: The connection of the RS485 in the HD67432-E4x-xxx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page. The connection of the RS485 in the HD67432-E7x-xxx device must be made with a AMP SuperSeal 1.5 Male connector.
Page 11: Can
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 11 of 32 Industrial Electronic Devices CAN: The connection of the J1939 in the HD67432-E4x-xxx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page. The connection of the J1939 in the HD67432-E7x-xxx device must be made with a AMP SuperSeal 1.5 Male connector.
Page 12: Usb
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 12 of 32 Industrial Electronic Devices USB: The USB port is used to start the converter in Boot Mode and to program the converter. It is necessary to use a Micro USB type B cable. ADFweb.com Srl –...
Page 13: Use Of Compositor Sw67432
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 13 of 32 Industrial Electronic Devices USE OF COMPOSITOR SW67432: To configure the Converter, use the available software that runs with Windows called SW67432. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 14: New Project / Open Project
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 14 of 32 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “J1939 / Modbus Slave - Converter”...
Page 15: Software Options
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 15 of 32 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 16: Set Communication
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 16 of 32 Industrial Electronic Devices SET COMMUNICATION: This section defines the fundamental communication parameters of two buses, J1939 and Modbus. By pressing the “Set Communication” button from the main window for SW67432 (Fig. 2) the window “Set Communication Setting”...
Page 17: Receive J1939
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 17 of 32 Industrial Electronic Devices RECEIVE J1939: By pressing the “Receive J1939” button from the main window for SW67432 (Fig. 2) the window “Receive J1939 Frames” appears (Fig. 4). This section is used to define the J1939 messages accepted by the converter.
Page 18: Define Receive J1939
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 18 of 32 Industrial Electronic Devices DEFINE J1939: By pressing the “Define J1939” button near “Receive J1939” from the main window for SW67432 (Fig. 2) the window “Define Modbus Registers for Receive J1939 Frames”...
Page 19: Transmit J1939
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 19 of 32 Industrial Electronic Devices TRANSMIT J1939: By pressing the “Transmit J1939” button from the main window of SW67432 the window “Transmit J1939 Frames” appears (Fig. 6). This section is used to define the J1939 messages sent by the converter.
Page 20: Define Transmit J1939
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 20 of 32 Industrial Electronic Devices DEFINE J1939: By pressing the “Define J1939” button near “Transmit J1939” from the main window for SW67432 (Fig. 2) the window “Define Modbus Registers for Transmit J1939 Frames”...
Page 21: Update Device
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 21 of 32 Industrial Electronic Devices UPDATE DEVICE (ONLY FOR THE HARDWARE WITHOUT USB PORT): By pressing the “Update by CAN” button it is possible to load the created Configuration into the device; and also the Firmware, if is necessary.
Page 22: Update Device Usb
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 22 of 32 Industrial Electronic Devices UPDATE DEVICE USB: By pressing the “Update Device USB” button it is possible to load the created Configuration into the device, and also the Firmware if is necessary, using the USB port.
Page 23 User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 23 of 32 Industrial Electronic Devices Note: When you install a new version of the software it is better if the first time you do the update of the Firmware in the HD67432 device. Note: When you receive the device, for the first time, you have to update also the Firmware in the HD67432 device.
Page 24: Remote Request
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 24 of 32 Industrial Electronic Devices REMOTE REQUEST: In the “Priority and Destination” Register you have to indicate the Priority of the request in the high byte of the register (usually this value is equal to 6) and the Address of the Destination Device in the low byte of register.
Page 25: Mechanical Dimensions
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 25 of 32 Industrial Electronic Devices MECHANICAL DIMENSIONS: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 26 User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 26 of 32 Industrial Electronic Devices Type A ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 27 User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 27 of 32 Industrial Electronic Devices Type B ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 28 User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 28 of 32 Industrial Electronic Devices Type C ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 29 User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 29 of 32 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67432 – E y z – s d f Fixing lugs A: Type A B: Type B...
Page 30: Order Code
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 30 of 32 Industrial Electronic Devices ACCESSORIES: Order Code: AC34001 Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V AC Order Code: AC34002 Rail DIN - Power Supply 110V AC 50/60Hz – 12 V AC Order Code: AC67402 Cable Super Seal 1.5 MALE 2-pole - 1.0 Meter Order Code: AC67402-3 -...
Page 31: Disclaimer
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 31 of 32 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 32: Warranties And Technical Support
User Manual J1939 / Modbus Slave Document code: MN67432_ENG Revision 1.100 Page 32 of 32 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
