POWER SUPPLY:

The devices can be powered between a wide range of tensions. For more details see the two tables below.
VAC VDC
Vmin Vmax Vmin Vmax
HD67461-Exx-xxx
8V 26V 10V 40V
Consumption at 24V DC:
Device W/VA
HD67461-Exx-xxx 4
Caution: Not reverse the polarity power
HD67461-E4x-xxx HD67461-E7x-xxx
Note: It is possible to use also negative tensions. In this case the polarity must be inverted.
