392 SERVICING AND MAINTENANCE
Assembly Bracket
4. Rotate the appropriate socket a quarter
turn counterclockwise, then remove it from
the housing.
5. Pull the bulb straight from the socket to
replace.
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
Please see an authorized dealer for service.
See below steps to replace:
LICENSE PLATE LAMPS
See below steps to replace:
1. Reach under the vehicle to access the
back of the lamp.
2. Firmly grab the bulb by the two latch
features and squeeze them together.
3. When squeezing the latch features
together, pull down on the lamp to remove it
from the license plate bracket assembly
and expose the bulb socket.
4. Twist the bulb socket 90 degrees counter-
clockwise to unlock the socket and
separate the socket from the lamp.
5. Firmly grab the bulb and pull it from the
socket.
To install a new bulb, reverse the procedure.
NOTE:
When installing a new bulb, care should be
taken to not allow bare skin to come in contact
with the bulb.
REAR FOG LAMP
NOTE:
We advise referring to an authorized dealer for
service.
See below steps to replace:
1. Reach under the vehicle to access the
back of the fog lamp.
2. Disconnect the wire harness connector
from the fog lamp connector receptacle.
3. Rotate the socket a quarter turn counter-
clockwise, then remove it from the housing.
4. Pull the bulb straight out from the keyed
opening in the housing and then connect
the replacement bulb and reassemble.
CAUTION!
Do not touch the new bulb with your fingers.
Oil contamination will severely shorten bulb
life. If the bulb comes in contact with any oily
surface, clean the bulb with rubbing alcohol.

TIRES

T S I
IRE AFETY NFORMATION
Tire safety information will cover aspects of the
following information: Tire Markings, Tire
Identification Numbers, Tire Terminology and
Definitions, Tire Pressures, and Tire Loading.
