1. Connect the diagnostic tool to the vehicle.
2. Launch the diagnostic App and select "Local Diagnosis" on the Job menu.
3. Follow the on-screen instructions to select the identified vehicle model and the
system to be calibrated.
A window with information and instructions appears.
*Caution: The radar reflector may drop when attaching it to the cross member and may
cuase injuries. You are strongly suggested to ask a second person to attach the reflector
to the cross member.
4. Refer to Chapter 4.1.3 to attach the radar reflector to the cross member. The radar
reflector must be within the radar sensor area.
5. Follow the instructions on the screen to calibrate the radar sensor.
