No.
Calibration pattern
The pattern varies from vehicle to vehicle. The default calibration pattern is
1
VAG Type 1(Front).
For detailed calibration reference patterns, please refer to Appendix.
Laser module
The actual value can be projected onto the scale of the 3 points wheel
alignment clamp with the help of the laser.
2
For details on the laser module, see Chapter 3.6.
*Note: This laser module features the same functions as that installed on the
wheel clamp.
Cover of cross member
3
All items mounted on the cross member be installed before closing the
covers on the cross member.
4 Right scale
5 Cross member
Left scale
6
Level gauge
7
8 Laser range finder
9 Handle
Laser module holder
For supporting and fixing the laser module.
*Note: To obtain accurate calibration result, please make sure that the laser
10
modules are evenly distributed and installed on the both ends of the cross
member.
Fixed bracket for calibration frame
11
Calibration frame
12
