LAUNCH
When the cross member is centrally located on the beam lifter, align the mouting
holes on the cross-linking bracket 2 with the floating screws on the cross member,
and then use the dedicated screws to fasten the cross member on the beam lifter.
*Note: If a thick film is covered on the cross member, please remove it from the cross
member when installing.
23
(c) Diagtools, Pernavas 43A, Riga, Latvia, www.diagtools.eu, +37129416069
X-431 ADAS PRO Calibration Tool User Manual
Fig. 4-2
