LAUNCH
*Caution: The calibration frame is heavy and may drop when installing and may cause
injuries. You are strongly suggested to ask a second person to install it together.
3. Mount the laser modules on the cross member: Mount the two laser modules on the
support base respectively ensuring the output of laser beam aimed at the wheel
clamp, and then use the set screws to fasten it.
25
(c) Diagtools, Pernavas 43A, Riga, Latvia, www.diagtools.eu, +37129416069
X-431 ADAS PRO Calibration Tool User Manual
Fig. 4-4a
Fig. 4-4b
Fig. 4-5
