are available on it.
Handle
2
For moving and holding the beam lifter easier.
Slider
For lifting the cross member up or dropping it along the lifter.
Note: There are two sliders pre-installed on each guide rail. To prevent the beam
3
lifter from shaking, you are strongly suggested to use the cross-linking bracket 3
to lock the sliders at the same time.
4 Mouting holes
Bearing
5 Never collide it abruptly when installing the beam lifter. Doing so may
cause damage to it.
Cross-linking bracket 1
6
7 Cross-linking bracket 2
Cross-linking bracket 3
8 A scale indicator is installed on the bracket for indicating the scale on the
beam lifter.
9 Feed screw nut
Tuning knob
10
Controls the ascending/descending speed of the slider (3).
Rocker switch
11
It has total 3 control levels: Up, Stop and Down.
