LAUNCH TECH X-431 ADAS PRO User Manual page 11

LAUNCH
No.
Base support
To firmly fasten the beam lifter to balance the cross member and
A
calibration frame installed on the lifter. Equipped with four rolling casters,
it also provides the ability to move the tool anytime and anywhere.
See Chapter 3.2 for details.
Cross member
It is installed on the beam lifter and supports the calibration frame. To
B
obtain more accurate result, ensure the cross member is centrally
mounted on the the beam lifter.
See Chapter 3.4 for details.
Calibration frame
Here you will need different calibration patterns depending on the car
C
manufacturer. These are optionally available.
See Chapter 3.4 for details.
Radar kit
There are three main components to the standard radar kit: radar
reflector, magnetic laser and attachment bracket. A corner reflector (See
D
Appendix) is also required if necessary.
See Chapter 3.7 for details.
*Note: Radar kit is required only when calibrating Radar-based ADAS.
3 Points Wheel Alignment clamp
It can be adjusted to best fit with the vehicle's tyre. A laser module so
E
that the vehicle is placed centred in front/rear of and in parallel with the
calibration tool.
See Chapter 3.6 for details.
Beam lifter
Connected to the AC outlet, it sits in the center of the base support and
F controls the height of the calibration frame. A scale ruler is also available
on it for reading the height of the calibration frame.
See Chapter 3.3 for details.
7
(c) Diagtools, Pernavas 43A, Riga, Latvia, www.diagtools.eu, +37129416069
X-431 ADAS PRO Calibration Tool User Manual
product improvements)
Description
