LAUNCH
X-431 ADAS PRO Calibration Tool User Manual
Fig. 4-3
2. Install the calibration frame: Hold the handles to lift the calibration frame up, and
insert it into the calibration frame holder at the same time until it reaches to the
bottom. See Fig. 4-4. Use the set screws to fix it.
24
