Depending on vehicle manufacturer, model and year of manufacture, the radar sensor
can be calibrated directly (without magnetic laser) or must be calibrated with the
magnetic laser.

5.3.1 Calibrating the radar sensor with magnetic laser

Proceed as follows to calibrate the radar sensor with the magnetic laser:
1. Connect the diagnostic tool to the vehicle.
2. Launch the diagnostic App and select "Local Diagnosis" on the Job menu.
3. Follow the on-screen instructions to select the identified vehicle model and the
system to be calibrated.
A window with information and instructions appears.
*Caution: The radar reflector may drop when attaching it to the cross member and may
cuase injuries. You are strongly suggested to ask a second person to attach the radar
reflector to the cross member.
4. Refer to Chapter 4.1.3 to attach the radar reflector to the cross member.
5. Turn the tuning lever at the manget base of the magnetic laser to ON. The
electromagnet becomes activated and the magnetic laser can be fixed onto the
radar reflector.
6. Switch on the laser beam with the switch of the magnetic laser.
*Caution: Laser radiation may cause damage to/destruction of the retina. Never look
directly into the laser beam.
7. Fix the magnetic laser onto the radar reflector. Make sure that the radar reflector
must be within the radar sensor area.
8. Direct the laser beam at the magnetic laser centred to the mirror of the radar sensor.
The laser beam will be reflected from the mirror to the scale of the magnetic laser.
9. Shift the magnetic laser slowly so that the horizontal and vertical level gauge
bubbles are centred.
10. Observe the on-screen prompt information and instructions to calibrate the radar
sensor.
11. After calibrating the radar sensor, switch off the laser beam on the magnetic laser.

5.3.2 Calibrating the radar sensor without magnetic laser

Proceed as follows to calibrate the radar sensor without the magnetic laser:
43
