LAUNCH
3.2 Base Support
No.
Mouting hole
1
For securing the beam lifter.
Adjustment screws
2
Use the adjustment screws to balance the level gauge of the base
support.
Rolling caster
3
Allows you to move the tool from one place to another place.
(c) Diagtools, Pernavas 43A, Riga, Latvia, www.diagtools.eu, +37129416069
X-431 ADAS PRO Calibration Tool User Manual
Fig. 3-2
Description
8
