Cortex GS6 PRO User Manual page 9

Key No. Description
71 Plate (4 holes)
72
Hex Bolt M8x10
74 Triceps Cable (4215mm)
75 Lat Cable (3380mm)
76 Butterfly Cable (3115mm)
77 C-clip
78 Triceps Rope
79 6 Chain
80 Lat Bar
81 Bar Grip
82 15 Chain
83 Small Bar Set
Bushing Φ38x5xΦ27x26
84
85 Small Bar Tube
86 Grip
87 Ankle Strap
88 Rear Base Frame
89 Base Frame
Upper Frame
90
91 Vertical Frame
Qty. Key No.
1 92
4 93
1 94
1 95
1 96
5 97
98
1
1 99
1 100
2 101
1 102
1 103
2 104
1 105
106
4
107
1
1 108
1 110
1 111
1
Description
Board
Foot Plate
Foot Plate Tube 270mm
End Caps
Support Tube
Foot Stand
Tube Plug 60x30
Parallel Support Bar
Lat Bar
Left Dip Arm
Right Dip Arm
Vertical Tube Bar
Bushing
Pipe Grip
Arm Pad
Pull Handle
Padded Back Support
Hex Bolt M8x65
L-Pin
GS6 PARTS LIST |
Qty.
1
1
1
2
2
1
2
1
1
1
1
2
2
2
2
1
1
4
1
9
