Internal Heights Drawing

Related Part Numbers

Product Name
OrbittyBox
Orbitty Carrier Board
NVIDIA® Jetson™ TX2
Active Heat Sink
Passive Heat Sink
SMA Cable – Female, U.FL CBG225
MSG066
* All products sold separately
Document: CTIM-00471
Revision: 0.14
Part Number
ENC001
ASG003
CMG503-21
XHG302
XHG301
Dual Band Antenna
Page 31 of 31
Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
www.connecttech.com
Date: 2021-10-05
Users Guide
