CURRENT CONSUMPTION DETAILS

Below are the maximum ratings of the Orbitty Carrier.
Theoretical Maximum
Theoretical absolute maximum total draw of all functionality on
the board
Below are measurements taken with the Orbitty Carrier running in various configurations. Some values
will change depending on what operation or software is installed. Please refer to the module
manufacturer's manual for full details on the current consumption of the particular module you are
using.
All measurements below are used with +12V applied to the Input Power Connector.
Actual Measurements
Orbitty Carrier standalone no module installed, powered ON,
with no loads
Module Installed, Ubuntu in headless mode, remote operation
over serial console
Module Installed, single HDMI video output, Keyboard, Mouse
and Ethernet connected. System sitting at Ubuntu Desktop
(GUI) in idle operation
Module Installed, single HDMI video output, USB 3.0 Camera
Connected, USB OTG connected with a Keyboard, and system
running cpu stress test and glxgears GPU test
Document: CTIM-00471
Revision: 0.14
Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Amps
1.75
Amps
0.03
0.12
0.20
0.71
Page 23 of 31
Users Guide
www.connecttech.com
Watts
21
Watts
0.36
1.44
2.4
8.52
