Ins ul ati n g Bon net
SPM - Code : V7xx xxVIx
D is asse m bly
S t ep 06
• Unscrew hexagon nuts (3.16)
R e asse m bly
S tep 06
• Grease stud screws
CAUT ION !
Lubrication as per Table 06 (Page 65)
• Screw hexagon nuts in place (3.16) and tighten in a
diagonally opposite sequence using the torque wrench
CAUT ION !
Nut tightening moment (3.16)
as per Table 04 (Page 64)
When tightening the nuts pay attention to the
alignment of the plug ( do not rub or insert the
plug in the open / closed movement )
