D is asse m bly
S t ep 02.1
• Unscrew hexagon nuts (1.4)
• Remove connection piece (4.2)
• Remove fl at gasket (1.2)
CAUT ION !
Remove remains of fl at gasket (1.2) in the body
and in the connection piece.
Do not damage sealing surface !
R e asse m bly
S tep 02.1
Reassembly takes place in reverse order.
CAUT ION !
Clean parts and check sealing surfaces for damage.
Use new fl at gasket (1.2) !
• Lay fl at gasket (1.2) in the connection piece
• Put complete body in place
CAUT ION !
Ensure it hangs vertically !
• Grease stud screws
CAUT ION !
Lubrication as per Table 06 (Page 65)
• Screw hexagon nuts in place (1.4) and tighten in a
diagonally opposite sequence using the torque wrench
CAU T ION !
Nut tightening moment (1.4)
as per Table 01 (Page 64)
When tightening the nuts pay attention to the
alignment of the plug ( do not rub or insert the
plug in the open / closed movement )
