Contents
1. Purpose
. Use
3. Description of the Procedure
4. Disassambling the Valve
5. Subassembly - Body
6. Subassembly - Trim
7. Subassembly - Bonnet
8. Subassembly - Packing
9. Technical Tables - Tightening Moments
10. Special Tools
CAUTI ON !
The Control Valve must only be disassembled and reassembled by qualified staff. Qualified staff is
defined as personnel who are familiar with the disassembling, reassembling, installation and commis-
sioning of this product and possess the relevant qualifications in their field of activity.
Follow the relevant Installation and Operating Instructions during installing, commissioning and oper-
ating !
Follow these Disassembly / Reassembly Instructions and only use original Spare Parts, as well as the
recommended Special Tools in order to guarantee perfect function and reliablity of this product.
Failure to comply with these Disassembly and Reassembly Instructions will render the manufacturer's
guarantee and liability null and void. Unless otherwise agreed, the manufacturer's General Terms and
Conditions of Sale shall apply.

Schmidt Armaturen
AI - FlowTop
Page
3
3
3
3 - 4
5 - 8
30 - 3
34 - 59
61 - 6
64 - 65
67
