1.3.2

I/O outlet

The following figures show you the locations of the OPS520 Series I/O outlets.

1.3.3

OPS520 Series is docked in the reference display panel

The OPS520 Pluggable Module docked at a display panel system.

In this reference design, the module is docked and undocked in the vertical direction.

NOTE: Please contact Axiomtek for available option display panel.
