Section 1 Introduction; General Description - AXIOMTEK OPS520 Series User Manual

This chapter contains general information and detailed specifications of the OPS520 Series.
Chapter 1 includes the following sections:
◼

General Description

◼ Specification
◼
Michanical Assembly
◼ Package List
1.1 General Description
Intel Open Pluggable Specification (OPS) Compliance
OPS520 Series is based on the 11
Q570/H510 Express Chipset platform and it also future products. The Pluggable Module is
dedicated to provide an interchangeable solution to the digital signage media players with
compatible connector. This document provides the module form factor, connector
specification, reference thermal solution, and boundary conditions in order to ensure the
functionally of the module in all compatible display panel system.
OPS520 Series meets Intel Open Pluggable Specification for design and development,
simplifying system upgrade maintenance for manufacturers and developers that supports
® th
Intel 11 Generation Core i series family, which stand for high flexible and user-friendly
digital signage applications.
Easy maintenance
OPS520 Series offers a best solution for digital signage market. Compliant with Intel OPS
architecture, digital signage players are capable of deploying interchangeable systems faster
and easing upgrading/maintenance, while lowering costs for development and implementation.
Additionally, having the ability to simply slot-in and out the unique pluggable engine box
makes daily hassle easier and faster for users.
OPS520 Series has pluggable engine box design; you can change storage, DRAM and
update configurations more easily
