Press PROGRAM key, note that the first programmable parameter is displayed and the
"Idle" message now indicates "Program".
1. To set the Mode:
Press
up/down arrow keys to scroll through Mode selections.
No Test Programmed
AC Total Current
AC Real Current
AC Imag Current
DC Current (not seen on Model 2510)
IR (Insulation Resistance Measurement) (not seen on Model 2510 or 2520)
GC Only (Ground Continuity Test)
"Imaginary" or
Capacitive
Component
Leave the display set for the selection desired and press
next parameter or PROGRAM key to exit program mode.
2. To set Voltage:
Press
up/down arrow keys to increase or decrease the voltage setting between 0.100KV
and 5.000KV (for AC Current) or 0.100KV and 6.000KV (for DC Current) or 0.050KV and
1.000KV (for Insulation Resistance).
Press
right arrow key to move to the next parameter (
parameter) or PROGRAM key to exit program mode.
Operation/Programming
1
Program
Mode: AC Total Current
"Total" Current
1
Program
Volt: 0.500KV
"Real'
or Resistive
Component
right arrow key to move to the
left arrow for previous
