Table 3–1 Mounting Hardware Description
Reference
Number
All manuals and user guides at all-guides.com
Mounting Hardware
Vertical nut bar
10-32 x .375-inch hex head screw
Bracket slide, right
Chassis slide
Nut plate, horizontal, slide
M4 x 10 mm, Bossard screw
Bracket slide, left
Bar nut
M3 x 6 mm flat head screw
Mounting rail, EIA (bars)
Front bezel
Actuator bracket, interlock
M5 x 8mm pan head, square cone washer
Nut keps, M4
10-32 x .5-inch hex head screw
M3 x 10 mm flat head screw (shown in Figure 3–12)
Screw Size
M3
M4
M5
10-32
Torque Value
7.6 in-lbs
17 in-lbs
20 in-lbs
21 in-lbs
Installing the Rackmount System 3-7
