To Install a PCI Option
1. Remove the screw
the slot cover from the system and store it for future use.
2. Carefully install the option module into the appropriate connector on the
system board and press it firmly into place.
3. Secure the module using the screw that you removed.
4. Replace the side cover (pedestal) or top cover (rackmount) and plug in the
power cords.
Verification
1. Turn on power to the system.
2. At the P00>>> prompt, enter the SRM show config command. Examine
the PCI bus information in the display to make sure that the new option is
listed.
3. If you installed a bootable device, enter the SRM show device command to
determine the device name.
To Remove a PCI Option
1. Disconnect any cables connected to the external (rear) or internal ports on
the option module you are removing.
2. Remove the slot cover screw securing the option module to the chassis.
3. Disconnect the option module from the slot connectors on the system board
and remove it from the system.
4. If you intend to leave the option slot vacant, install a slot cover and secure it
to the chassis using the screw that you removed.
5. Replace the side cover (pedestal) or top cover (rackmount) and plug in the
power cords.
All manuals and user guides at all-guides.com
securing the slot cover to the chassis and then remove
Configuring and Installing Components 5-13
