5.5.2 Pump alignment tolerances
Axial offset
2.
Determine alignment tolerances for coupling.
Permissible deviations and dimensions
data.
3.
Determine alignment tolerances for motor.
Permissible deviations and dimensions
data.
4.
Determine the lowest value from the ascertained alignment tolerances
(pump, coupling, motor) and apply this in order to align the coupling.
Fig. 10: Axial offset
Size
SLH-4U 10xx
SLH-4U 20xx
SLH-4U 30xx
03/2020 JP Rev. 1
Installation and connection
DKa
+1,0 mm
+1,0 mm
+1,0 mm
Type SLH-4U
manufacturer's
manufacturer's
33
