3.1.2 Type designation

3.2 Structure

Fig. 2: Type designation (example)
No.
1
2
3
The structure of the pump is shown here as an example only. The
dimensional drawing is the decisive source concerning the arrange-
ment of the inlet and outlet nozzles and the dimensions of the pump
( dimensional drawing).
03/2020 JP Rev. 1
Description
Series
Size
Conveyor screw incline [mm]
Type SLH-4U
Structure and function
17
