Transport and storage
22
Fig. 5: Fastening the lifting tackle to the pump
Fig. 6: Fastening the lifting tackle to the pump assembly
1.
Select the lifting equipment in accordance with the total weight to be trans-
ported (
2.
Fasten the lifting equipment per the preceding figures in accordance with
the markings on the pump.
3.
Ensure that the lifting tackle is not overly tensioned.
4.
Attach lifting tackle so that the pump/assembly cannot tip over axially.
5.
Lift the pump/assembly in a proper manner.
Type SLH-4U
The lifting eyelets and anchoring points for transport are labelled on
the pump.
dimensional drawings).
03/2020 JP Rev. 1
