Led Indicators - Ruijie RG-AP130(W2) V2 Series Hardware Installation And Reference Manual

Hardware Installation and Reference Guide
Figure 1-1 Image of RG-AP130(W2) V2
PoE/UpLink port, which is on the rear, is the 10/100/1000Base-T WAN port (PoE-capable).
Four 10/100/1000Base-T LAN ports are on the bottom.
Figure 1-2 Side View of RG-AP130(W2) V2
Note
1. Reset button
2. Micro USB management port (Console)

1.3 LED Indicators

3. DC power adapter port
4. Screw hole
Product Overview
·
