Hardware Installation and Reference Guide
Figure 1-4 Rear View of RG-AP180
Note 1. 10/100/1000Base-T Ethernet WAN port

1.3 LED Indicators

Figure 1-5 Indicator on the AP
Fat AP Mode
State Frequency
Off N/A
Fast blinking 2.5Hz (fast
green before blinking green)
solid green
Fast blinking 2.5Hz
red
Blinking orange 1Hz
Fit AP Mode
State Frequency
Off N/A
Meaning
The AP is powered off. Or the AP is in Silent mode, which can be disabled via
software.
Initialization is in progress. The AP is operational.
Firmware upgrade in progress. Do not power off the AP.
AP is operational.
Meaning
The AP is powered off. Or the AP is in Silent mode, which can be disabled via
