Note
1. Reset button
2. LED indicator
3. Anti-Theft lock hole

1.3 LED Indicators

Fit AP
State Frequency
Off N/A
Blinking green 3Hz
Solid green N/A
3Hz
Blinking red
2Hz
Solid orange N/A
Blinking orange 3Hz
Solid blue N/A
Blinking blue 3Hz
Pressed for less
than 2s
Reset button
Pressed for more
than 3s
Fat AP
4. RJ45 Console port
5. LAN/PoE port
6. 48V DC power port
Meaning
The AP is NOT receiving power. Or the AP is in Do Not Disturb mode, which
can be disabled by software.
uBoot program initialization in progress
Main program initialization in progress
Initialization is complete, but no Ethernet activity.
Locates the AP.
Initialization is complete, and the AP is establishing a CAPWAP connection
with an AC.
Firmware upgrade in progress. Do not power off.
Normal operation, but no wireless clients are associated with the AP.
Normal operation, at least one wireless client is associated with the AP.
Reboots the device.
Restores default settings.
·
