The weight refers to the weight of host and bracket.

1.2 Product Image

The AP provides one reset button and two ports, including one Ethernet port (PoE-capable), and one power port for
external power supply.
Figure 1-1 Top Panel of RG-AP210-L

1.3 LED Indicators

Fit AP
State Frequency
Off N/A
Blinking green 3Hz
Blinking red 3Hz
Blinking blue 3Hz
Blinking yellow 3Hz
Solid blue N/A
Solid green N/A
Pressed for 2s or
Reset
less
(Fit/Fat
Pressed for 3s or
switchover)
more
EN301 489
EN 55032
EN 61000
EN 55035
Meaning
The AP is NOT receiving power.
Initialization in progress
Initialization is complete, but no Ethernet activity.
Initialization is complete, the wired port is connected, and the AP is establishing
a CAPWAP connection with an AC.
Firmware upgrade in progress. Do not power off.
Normal operation, but no wireless clients are associated with the AP.
Normal operation, at least one wireless client is associated with the AP.
The AP is rebooted.
Factory settings are restored.
·
