- Page 1 Ruijie RG-AP110-L Access Points Hardware Installation and Reference Guide V1.0...
- Page 2 Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks is prohibited. Exemption Statement This document is provided “as is”.
- Page 3 It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support...
-
Page 4: Product Overview
1 Product Overview RG-AP110-L, which features a simple design and is easy to deploy, is designed for SMB scenarios. This 802.11n-based AP can be installed on an 86-type faceplate mounting box without damaging interior trim, which makes it an ideal choice for SMBs like hotels. - Page 5 Hardware Installation and Reference Guide Product Overview Figure 1-1 Front View of RG-AP110-L · Figure 1-2 Rear View of RG-AP110-L 1.3 LED Indicator and Reset Button Figure 1-3 Indicator and Reset Button on the AP...
- Page 6 Hardware Installation and Reference Guide Product Overview · Meaning LED/Button Frequency Fast blinking Initialization is in progress. (2.5Hz) AP is operational and CAPWAP connection is established. No STA is Solid associated. System Double blinking Ethernet link is down. (Blue) (1Hz) Single blinking Ethernet link is up.
-
Page 7: Preparing For Installation
Hardware Installation and Reference Guide Preparing for Installation · 2 Preparing for Installation 2.1 Safety Suggestions To ensure normal operation and a prolonged useful life of the equipment, the installation site must meet the following requirements. To prevent device damage and bodily injury, please read carefully the safety recommendations described in this chapter. ... -
Page 8: Emi Consideration
Hardware Installation and Reference Guide Preparing for Installation Besides, the contents of salts, acids and sulfides in the air are also strictly limited for the equipment room. These · substances can accelerate metal corrosion and the aging of some parts. Table 2-3 describes the limit of some hazardous gases such as SO S, NO and Cl... -
Page 9: Installing The Access Point
Hardware Installation and Reference Guide Installing the Access Point · 3 Installing the Access Point Make sure you have carefully read Chapter 2, and be sure that the requirements set forth in Chapter 2 have been met. Remove the 86-type faceplate from the wall with a screwdriver. Figure 3-1 Removing the 86-Type Faceplate Connect the Ethernet cable to the WAN port. - Page 10 Hardware Installation and Reference Guide Installing the Access Point Attach the faceplate cover onto the access point. · Figure 3-4 Attaching the Cover...
-
Page 11: System Debugging
Hardware Installation and Reference Guide System Debugging · 4 System Debugging 4.1 Setting up a Debugging Environment Use PoE to power the AP. PoE power supply To use a PoE device, make sure the peer end supports the IEEE 802.3af or 802.3at PoE standard. Then, connect the Ethernet cable to the WAN on the AP. -
Page 12: Monitoring And Maintenance
5 Monitoring and Maintenance 5.1 Monitoring You can observe the LED to monitor the AP in operation. For details, refer to Chapter 1.3 LED Indicator and Reset Button. 5.2 Hardware Maintenance When exceptions occur, contact Ruijie TAC for professional support. -
Page 13: Troubleshooting Flowchart
Hardware Installation and Reference Guide Troubleshooting · 6 Troubleshooting 6.1 Troubleshooting Flowchart 6.2 Troubleshooting The LED does not light up after the AP is powered on Verify that the power source is at least IEEE 802.11af compliant. And then verify that the cable is properly connected. The WAN port does not work after the Ethernet cable is connected Verify that the device at the other end of the Ethernet cable is working properly. - Page 14 Hardware Installation and Reference Guide Troubleshooting Verify that the AP is configured correctly. · Move the client device to adjust the distance between the client and the AP. The installation instruction above is based on RG-AP110-L. The actual product prevails.
-
Page 15: Appendix A Connectors And Media
Hardware Installation and Reference Guide Appendix A Connectors and Media · Appendix A Connectors and Media 100BASE-TX/10BASE-T The 100BASE-TX/10BASE-T is a 10/100 Mbps auto-negotiation port that supports auto MDI/MDIX. 10BASE-T uses Category 3, 4, 5 100-ohm UTP/STP and 1000BASE-T uses Category 5 100-ohm UTP/STP for connections. -
Page 16: Appendix B Cabling Recommendations
Hardware Installation and Reference Guide Appendix B Cabling Recommendations · Appendix B Cabling Recommendations During installation, route cable bundles upward or downward along the sides of the rack depending on the actual situation in the equipment room. All cable connectors should be placed at the bottom of the cabinet rather than be exposed outside of the cabinet. - Page 17 Hardware Installation and Reference Guide Appendix B Cabling Recommendations · If cables are to be bent, bind them first but do not tie cable ties within the bend to avoid stress on the cables, which may otherwise cause the wires inside to break, as shown in Figure B-3. Figure B-3 Do Not Tie Cable Ties within the Bend ...
- Page 18 Hardware Installation and Reference Guide Appendix B Cabling Recommendations · 1. Flat washer 3. Spring washer Note 2. Nut 4. Flat washer When using a stiff cable, fix it near the cable lug to avoid stress on the lug and cable. ...
