Hardware Installation and Reference Guide

1.3 LED Indicators

Fit AP
State Frequency
Off N/A
Blinking green 3Hz
Solid green N/A
Blinking red 3Hz
Solid orange N/A
Blinking orange 3Hz
Solid blue N/A
Blinking blue 3Hz
Double blinking 3Hz (on and off for
red 2 cycles
alternately)
Reset button Pressed for less
than 2s
Pressed for more
than 3s
Fat AP
State Frequency
Off N/A
Blinking green 3Hz
Solid green N/A
Blinking red 3Hz
Solid blue N/A
Blinking blue 3Hz
Reset button Pressed for less
than 2s
Pressed for more
than 3s

1.4 Power Sources

The AP can be powered either with a power adapter or through a PoE+ device.
If an adapter is chosen to power the AP, make sure it meets the requirements set by Ruijie.
Meaning
The AP is NOT receiving power. This mode can be disabled using software.
uBoot program initialization in progress.
Main program initialization in progress.
Initialization is complete, but LAN1 and LAN2 ports are not connected.
Initialization is complete, and the AP is establishing a CAPWAP connection
with a wireless controller.
Firmware upgrade in progress. Do not power off.
Normal operation and normal CAPWAP connection; no wireless clients are
associated with the AP.
Normal operation, and normal CAPWAP connection; at least one wireless
client is associated with the AP.
Locating AP
Restarts the AP.
Restores the factory default settings.
Meaning
The AP is powered off or in Silent mode. This mode can be disabled by
software.
uBoot program initialization in progress.
Main program initialization in progress.
Initialization is complete, but LAN1 and LAN2 ports are not connected.
Normal operation; no wireless clients are associated with the AP.
Normal operation; at least one wireless client is associated with the AP.
Restarts the AP.
Restores the factory default settings.
